IMPULSE®•G+ & VG+ Series 4 Instruction Manual – February 2017
5-3
Introduction
This chapter features parameters that are available only when the Series 4 drive is in Advanced
mode.
Application
• B1 Preset References
• B2 Reference Limits
• B3 Sequence/Reference Source
• B5 Acceleration/Deceleration
• B8 Jump Frequencies
Preset Reference
Table 5-1: Preset Reference Parameter Settings
Parameter Display Function Range** Default
B01-01 Reference 1 Sets the Speed 1 frequency. 0.00–E01-04 Hz 15.00*
B01-02 Reference 2 Sets the Speed 2 frequency. 0.00–E01-04 Hz 30.00*
B01-03 Reference 3 Sets the Speed 3 frequency. 0.00–E01-04 Hz 60.00*
B01-04 Reference 4 Sets the Speed 4 frequency. 0.00–E01-04 Hz 0.00*
B01-05 Reference 5 Sets the Speed 5 frequency. 0.00–E01-04 Hz 0.00*
B01-06 Reference 6 Sets the Speed 6 frequency. 0.00–E01-04 Hz 0.00*
B01-07 Reference 7 Sets the Speed 7 frequency. 0.00–E01-04 Hz 0.00*
B01-08 Reference 8 Sets the Speed 8 frequency. 0.00–E01-04 Hz 0.00*
B01-09 Reference 9 Sets the Speed 9 frequency. 0.00–E01-04 Hz 0.00*
B01-10 Reference 10 Sets the Speed 10 frequency. 0.00–E01-04 Hz 0.00*
B01-11 Reference 11 Sets the Speed 11 frequency. 0.00–E01-04 Hz 0.00*
B01-12 Reference 12 Sets the Speed 12 frequency. 0.00–E01-04 Hz 0.00*
B01-13 Reference 13 Sets the Speed 13 frequency. 0.00–E01-04 Hz 0.00*
B01-14 Reference 14 Sets the Speed 14 frequency. 0.00–E01-04 Hz 0.00*
B01-15 Reference 15 Sets the Speed 15 frequency. 0.00–E01-04 Hz 0.00*
B01-16 Reference 16 Sets the Speed 16 frequency. 0.00–E01-04 Hz 0.00*
B01-17 Jog Reference
Jog Control and Inching Control
frequency reference.
0.00–E01-04 Hz 6.00
B01-18 Ref Priority Determines whether the digital or
analog frequency reference is
used. NOTE: When using Higher
Reference Select, Infinitely
Variable should NOT be used for a
Speed Reference setting in
parameter A01-04. The two
functions are not intended to work
in conjunction.
0–2 0*
0 Digital Ref Only
1 Analog Ref Only
2 Higher RefSelect
* Initial value is determined by X-Press Programming (Table 4-6, 4-7, or 4-8 on pages 4-12, 4-13, and 4-14).
** Consult Magnetek for frequencies above 150 Hz.
