IMPULSE®•G+ & VG+ Series 4 Instruction Manual – February 2017
5-9
Motor Rotation Change
This parameter allows you to change the motor direction without changing the motor leads.
Table 5-6: Motor Rotation Parameter Settings
NOTE: To reverse the direction of rotation, program B03-04 = 1 (exchange phases), or
interchange any two motor leads (changing R/L1, S/L2, or T/L3 will not affect the shaft
rotation direction) as well as encoder phasing (F01-02 = 0/1 or swapping A and A
wires).
Zero-Speed Operation
This parameter sets the drive behavior when the frequency reference is below the Zero Speed level.
Table 5-7: Zero-Speed Operation Parameter Settings
Input Scan Time
B03-06 selects the microprocessor scan time for reading the status of the input control terminals. Set
B03-06 to “0” when a quicker response is needed from the control circuit terminal.
Table 5-8: Input Scan Time Parameter Settings
LO/RE Run Select
If the run reference/speed reference is switched between serial mode and drive terminal mode,
B03-07 determines action after the switch.
Parameter Display Function Range Default
B03-04 Change Rotation Reverse motor direction 0, 1 0
0 Standard
1 SwitchPhaseOrder Switch phase order (reverses the
direction of the motor
Parameter Display Function Range Default Model
B03-05 Zero-Speed Oper Operation Selection at Zero
Speed.
0–3 0
0 RUN at Freq Ref Operate according to the
Frequency Reference
VG+
1STOP Coast when the Frequency
Reference is below E01-09
VG+
2 RUN at Min Freq Output the Frequency set in E01-
09
VG+
3 RUN at Zero RPM Operate at zero speed VG+
Parameter Display Function Range Default
B03-06 Cntl Input Scans Selects the terminal scan time 0, 1 1
01 Scan 1 ms
12 Scans 2 ms
