Digital Output (DO-A3) and S4IO Option Set-up
Selects the multi-function digital output settings for channels 1 through 8 of the DO-A3 and S4IO
option cards.
Table 5-67: Digital Output Set-Up Parameter Settings
Parameter Display
Terminal Designation
Range Default
DO-A3 S4IO
F05-01* DO Ch1 Select M1-PC O1-O2 0–148 F
F05-02* DO Ch2 Select M2-PC O3-O2 0–148 F
F05-03* DO Ch3 Select M3-PC O4-O5 0–148 F
F05-04* DO Ch4 Select M4-PC O6-O5 0–148 F
F05-05* DO Ch5 Select M5-PC -- 0–148 F
F05-06* DO Ch6 Select M6-PC -- 0–148 F
F05-07* DO Ch7 Select M1-M2 -- 0–148 F
F05-08* DO Ch8 Select M3-M4 -- 0–148 F
F05-09 DO Function Sel Selects how the DO-A3 option
card will work with the drive.
0–2 2
0 8ch Individual
1 Binary Output
28ch Selected
* See Table 5-76 for MFDO selections.
