IMPULSE®•G+ & VG+ Series 4 Instruction Manual – February 2017
5-84
Ethernet Option Card Set-up (Ethernet IP & Modbus TCP/IP)
Settings for communication option cards SI-EN3 and SI-EM3.
Table 5-70: Communication Option Card Parameter Settings
F06-55 DN BAUD RATE MEM Displays the baud rate of the
DeviceNet network. (Read Only -
Monitor)
0–2 0
0 125 kbps
1 250 kbps
2 500 kbps
F06-56 DN Speed Scale Sets the scaling factor for the
speed monitor in DeviceNet.
-15–15 0
F06-57 DN Current Scale Sets the scaling factor for the
output current monitor in
DeviceNet.
-15–15 0
F06-58 DN Torque Scale Sets the scaling factor for the
torque monitor in DeviceNet.
-15–15 0
F06-59 DN Power Scale Sets the scaling factor for the
power monitor in DeviceNet.
-15–15 0
F06-60 DN Voltage Scale Sets the scaling factor for the
voltage monitor in DeviceNet.
-15–15 0
F06-61 DN Time Scale Sets the scaling factor for the
time monitor in DeviceNet.
-15–15 0
F06-62 DN Heart Beat Sets the heartbeat interval for
DeviceNet communications.
A setting of 0 disables the
heartbeat.
0–10 0
F06-63 DN MAC ID MEM Displays the DeviceNet MacID
assigned to the drive (Read Only -
Monitor).
0–63 0
Parameter Display Function Range Default
Parameter Display Function Range Default
F07-01 IP Address 1 IP Address 1 0–255 192
F07-02 IP Address 2 IP Address 2 0–255 168
F07-03 IP Address 3 IP Address 3 0–255 1
F07-04 IP Address 4 IP Address 4 0–255 20
F07-05 Subnet Mask 1 Subnet Mask 1 0–255 255
F07-06 Subnet Mask 2 Subnet Mask 2 0–255 255
F07-07 Subnet Mask 3 Subnet Mask 3 0–255 255
F07-08 Subnet Mask 4 Subnet Mask 4 0–255 0
F07-09 Gateway IP Add 1 Gateway Address 1 0–255 192
F07-10 Gateway IP Add 2 Gateway Address 2 0–255 168
F07-11 Gateway IP Add 3 Gateway Address 3 0–255 1
F07-12 Gateway IP Add 4 Gateway Address 4 0–255 1
F07-13 IP Add Mode Sel Sets how the option card IP
Address is set at start up
0–2 2
0 User Defined
1BOOTP
2 DHCP
To Next Page
