Magnetek Impulse G+ series 4 User Manual

IMPULSE®•G+ & VG+ Series 4 Instruction Manual – February 2017
5-83
F06-31 PB Clear Select Determines the operation when a
“Clear Mode” command is
received on the Profibus-DP
option Card
0, 1 0
0 Reset to Zero Resets drive operation with a
Clear mode command.
1 Hold Prev Value Maintains the previous operation
state when Clear mode command
is given.
F06-32 PB Map Select Selects the data format used for
Profibus-DP communications.
0, 1 0
0 PPO Type
1 Conventional
F06-35 CO Node Address Sets the node address if a
CANopen option card is installed.
0–126 0
F06-36 CO Baud Rate Sets the baud rate for the
CANopen option card
0–8 6
0 Auto Detect
1 10 kbps
2 20 kbps
3 50 kbps
4 125 kbps
5 250 kbps
6 500 kbps
7 800 kbps
81 Mbps
F06-50 DN MAC Address Sets the MacID address of the
DeviceNet option card.
0–64 64
F06-51 DN Baud Rate Sets the baud rate for the
DeviceNet option card.
0–4 4
0 125 kbps
1 250 kbps
2 500 kbps
3 Set from Network
4 Automatic
F06-52 DN PCA Selection Sets the format of the data
received from the DeviceNet
master to the drive.
0–255 21
F06-53 DN PPA Selection Sets the format of the data sent
from the drive to the DeviceNet
master.
0–255 71
F06-54 DN Idle Flt Det Selects whether the drive triggers
an EF0 fault when no data is
received from the DeviceNet
master (such as when the master
is idling).
0, 1 0
0 Enabled
1 Disabled No fault detection
Parameter Display Function Range Default
