IMPULSE®•G+ & VG+ Series 4 Instruction Manual – February 2017
5-97
Analog Inputs
The IMPULSE
®
•G+ and VG+ Series 4 has three built-in analog inputs for the external input of
numerous references and limits. Drive analog input capabilities can be increased with the installation
of an AI-A3 option card.
Table 5-81: Analog Inputs Parameter Settings
Parameter Display Function Range Default
H03-01 Term A1 Signal Voltage for Terminal A1 analog input
signal
0, 1 *
0 0 to 10 V
1 -10 to 10 V
H03-02 Terminal A1 Sel Sets the function of terminal A1 (see
tables 5-82 and 5-83 for option
selections).
0–31 *
H03-03 Terminal A1 Gain Sets the level of the input value
selected in H03-02 when 10 V is input
at terminal A1.
-999.9–999.9% 100.0
H03-04 Terminal A1 Bias Sets the level of the input value
selected in H03-02 when 0 V is input
at terminal A1.
-999.9–999.9% 0.0
H03-05 Term A3 Signal Voltage for Terminal A3 analog input
signal
0, 1 0
0 0 to 10 V
1 -10 to 10 V
H03-06 Terminal A3 Sel Sets the function of terminal A1 (see
tables 5-82 and 5-83 for option
selections).
0–31 *
H03-07 Terminal A3 Gain Gain multiplier for Terminal A3 analog
input signal
-999.9–999.9% 100.0
H03-08 Terminal A3 Bias Bias multiplier for Terminal A3 analog
input signal
-999.9–999.9% 0.0
H03-09 Term A2 Signal Terminal A2 Signal Level Selection 0–3 2
0 0 to 10 V
1 -10 to 10 V
2 4 to 20 mA
3 0 to 20 mA
NOTE: Use DIP switch S1 to set input terminal A2 for a
current or a voltage input signal.
H03-10 Terminal A2 Sel Sets the function of terminal A2 (see
tables 5-82 and 5-83 for option
selections).
0–31 1F
H03-11 Terminal A2 Gain Gain multiplier for terminal A2 analog
input signal
-999.9–999.9% 100.0
H03-12 Terminal A2 Bias Bias multiplier for terminal A2 analog
input signal
-999.9–999.9% 0.0
H03-13 Filter Avg Time Analog input filter average time 0.00–2.00sec 0.03
* Initial value is determined by X-Press Programming (Table 4-6, 4-7, or 4-8 on pages 4-12, 4-13, and 4-14).
