IMPULSE®•G+ & VG+ Series 4 Instruction Manual – February 2017
5-98
Table 5-82: Option Selections for H03-02, H03-06, and H03-10 (Flux Vector)
H03-14 A1/A2/A3 Sel Determines which analog input
terminals will be enabled when a
digital input programmed for “MFAI
Enable” (H01-xx = 3A) is activated.
1–7 7
1 A1 Available
2 A2 Available
3 A1/A2 Available
4 A3 Available
5 A1/A3 Available
6 A2/A3 Available
7 All Available
H03-15 TerminalA1Offset Adds an offset when the analog signal
to terminal A1 is 0V
-500–500 0
H03-16 TerminalA2Offset Adds an offset when the analog signal
to terminal A2 is 0V
-500–500 0
H03-17 TerminalA3Offset Adds an offset when the analog signal
to terminal A3 is 0V
-500–500 0
Display Function
0 Analog Freq Ref1 Analog Frequency reference 1
10V = E01-04 (Maximum output frequency)
1 Frequency Gain The value of the analog frequency reference will be multiplied with the
analog frequency reference gain value.
2 Analog Freq Ref2 Analog Frequency reference 2
10V = E01-04 (Maximum output frequency)
3 Analog Freq Ref3 Analog Frequency reference 3
10V = E01-04 (Maximum output frequency)
5 Acc/Dec T Reduct 10V = 100%
7 OT / UT Det Lvl Motor rated torque (vector control); inverter rated current (V/f control)
9 Ref Lower Limit Max. output frequency
10V = E01-04 (Maximum output frequency)
D Freq Ref Bias 2 The input value of an analog input set to this function will be added to the
frequency reference. This function can be used with any frequency
reference source.
E MotorTemperature
10 FWD Torque Limit Torque limit when motoring in the forward direction.
11 REV Torque Limit Torque limit when motoring in the reverse direction.
12 Regen Torque Limit Torque limit during regen.
13 Torque Reference Torque reference when in Torque Control mode; Torque limit when in
Speed Control mode.
14 Torque Comp
15 Torque Limit Torque limit when motoring.
16 Load Cell Used for Weight Measurement and/or Load Check
1F Not Used --
Parameter Display Function Range Default
* Initial value is determined by X-Press Programming (Table 4-6, 4-7, or 4-8 on pages 4-12, 4-13, and 4-14).
