IMPULSE®•G+ & VG+ Series 4 Instruction Manual – February 2017
5-99
Table 5-83: Option Selections for H03-02, H03-06, and H03-10 (V/f)
Display Function
0 Analog Freq Ref1 100% = Max output frequency (E01-04) Same value can be set using
H03-02 and H03-10.
10V = E01-04 (Maximum output frequency)
1 Frequency Gain The value of the analog frequency bias will be multiplied with the analog
frequency reference gain value.
2 Analog Freq Ref2 Max. output frequency
10V = E01-04 (Maximum output frequency)
3 Analog Freq Ref3 Max. output frequency
10V = E01-04 (Maximum output frequency)
4 Voltage Bias Output Voltage Bias. This bias boosts the output voltage of the V/f curve
as a percentage of the maximum output voltage (E01-05). Only available
in V/f mode.
Motor rated voltage (E01-05)
10V = E01-05 (Motor rated Voltage)
5 Acc/Dec T Reduct 10V = 100%
6 DC Inj Braking DC Injection Braking Current
10V = 100% Drive rated current
4 to 20 mA = 0 to 100% Drive rated current
7 OT / UT Det Lvl Motor rated torque (vector control); inverter rated current (V/f control)
8 Stall Prev Level
9 Ref Lower Limit Max. output frequency
10V = E01-04 (Maximum output frequency)
D Freq Ref Bias 2 The input value of an analog input set to this function will be added to the
frequency reference. This function can be used with any frequency
reference source.
E MotorTemperature
16 Load Cell Used for Weight Measurement and/or Load Check
1F Not Used --
