IMPULSE®•G+ & VG+ Series 4 Instruction Manual – February 2017
5-85
F07-14 Duplex Select Sets how the communication
between host/client will be
determined
0–2 1
0 Half Duplex
1 Auto Negotiate
2 Full Duplex
F07-15 Baud Rate Sets the communication speed for
the option card.
10, 100 Mbps 10
10 10 Mbps
100 100 Mbps
F07-16 CommLoss Tout Sets the time-out value for
communication loss detection in
tenths of a second. A value of 0
disables the connection time-out.
Example: an entered value of 100
represents 10.0 seconds.
0–300 deciseconds 0
F07-17 EN Speed Scale Sets the scaling factor for the
EtherNet/IP speed setting/monitor
-15–15 0
F07-18 EN Current Scale Sets the scaling factor for the
EtherNet/IP output current setting/
monitor
-15–15 0
F07-19 EN Torque Scale Sets the scaling factor for the
EtherNet/IP torque setting/monitor
-15–15 0
F07-20 EN Power Scale Sets the scaling factor for the
EtherNet/IP power monitor
-15–15 0
F07-21 EN Voltage Scale Sets the scaling factor for the
EtherNet/IP voltage setting/
monitor
-15–15 0
F07-22 EN Time Scale Sets the scaling factor for the
EtherNet/IP time setting/monitor
-15–15 0
F07-23 to
F07-32
DOA116 (1 to 10) Dynamic parameters that contain
the MEMOBUS/Modbus
addresses used for programmable
registers in the output assembly
116. Data residing in bites 20 to 39
of assembly 116 will be written to
the respective MEMOBUS/
Modbus registers identified by the
addresses contained in these
parameters. No data is written to
the MEMOBUS/Modbus registers
if the parameter setting is 0.
Modbus Address
0x- - - -
0
F07-33 to
F07-42
DOA166 (1 to 10) Dynamic parameters that contain
the MEMOBUS/Modbus
addresses used for programmable
registers in the input assembly
166. Data residing in the
MEMOBUS/Modbus registers will
be written to the respective
assembly 166 bytes 20 to 39. The
MEMOBUS/Modbus registers are
identified by the addresses
contained in these parameters. No
data is written to the
programmable registers if the
parameter setting is 0.
Modbus Address
0x- - - -
0
Parameter Display Function Range Default
