Magnetek Impulse G+ series 4 User Manual

IMPULSE®•G+ & VG+ Series 4 Instruction Manual – February 2017
5-54
C13-12 Index Brake Ctrl Configures brake behavior when
indexing (traverse only).
TRAV: 0–2
NLB: 0, 2
NLB: 2
else: 0
VG+
0 Open on Index Brake will open on Index Cmd and
remain open until Index Cmd is
OFF. Drive is in Load Float
between runs.
1 Open on each Run Brake will open on Run cmd and
close when run is finished, or after
Load Float in NLB.
2 Ltch Open on Run Brake will open on Run cmd and
remain open with drive in Load
Float until Index is turned off.
Parameter Display Function Range Default Model
** If both C13-04 and C13-05 = 0, the Index function is disabled.
