IMPULSE®•G+ & VG+ Series 4 Instruction Manual – February 2017
5-101
618 PG1
CounterValue
619 PG2
CounterValue
622 Zero Servo Pulse
625 ASR Out w/o Fil
626 FF Cont Output
627 FF Estimate SPD
H04-02 Terminal FM Gain Gain multiplier for Terminal FM
analog output signal
-999.9–999.9% 100.0
H04-03 Terminal FM Bias Bias multiplier for Terminal FM
analog output signal
-999.9–999.9% 0.0
H04-04 Terminal AM Sel Assigns one of the above function
analog output parameters to
Terminal AM
000–630 103
H04-05 Terminal AM Gain Gain multiplier for Terminal AM
analog output signal
-999.9–999.9% 50.0
H04-06 Terminal AM Bias Bias multiplier for Terminal AM
analog output signal
-999.9–999.9% 0.0
H04-07 FM Level Select Sets the voltage output level of U
Monitor data for Terminal FM
(Some monitors may not be
assigned)
0–2 0
0 0 to 10 V
1 -10 to 10 V
2 4 to 20 mA (Terminal FM only)
H04-08 AM Level Select Sets the voltage output level of U
Monitor data for Terminal AM
(Some monitors may not be
assigned)
0–2 0
0 0 to 10 V
1 -10 to 10 V
2 4 to 20 mA Only available for 24 VDC
interface card
Parameter Display Function Range Default
