IMPULSE®•G+ & VG+ Series 4 Instruction Manual - February 2017
1-7
Table 1-3: Specifications for 230 V, 460 V, and 575 V
Specification Specification Value and Information for All Models
Certification UL, cUL, CSA, CE, RoHS
Crane Duty Classification Rated for CMAA Crane Duty Class A - F only (or equivalent)
Rated input power supply volts
& freq
3-phase 200 to 240 VAC 50/60 Hz for a 230 VAC-rated drive
3-phase 380 to 480 VAC 50/60 Hz for a 460 VAC-rated drive
3-phase 500 to 600 VAC 50/60 Hz for a 575 VAC-rated drive
Control Voltage 120 VAC (50/60 Hz) standard
42–48 VAC (50/60 Hz)
24 VAC (50/60 Hz)
24 VDC
Allowable input and control
voltage fluctuation
+10% or -15% of nominal
Allowable input frequency
fluctuation
±5% of nominal
Allowable control frequency
fluctuation
±3 Hz of nominal
Control method Fully digital, V/f, open loop vector, or flux vector control; sine-wave, pulse-
width-modulated
Maximum output voltage (VAC) 3-phase 200 to 240 VDC (proportional to input voltage)
3-phase 380 to 480 VDC (proportional to input voltage)
3-phase 500 to 600 VDC (proportional to input voltage)
Rated frequency (Hz) 150 Hz standard (400 Hz optional, consult factory and equipment
manufacturer)
Output speed control range FLV: 1500:1; OLV: 200:1; V/f: 40:1
Output frequency accuracy 0.01%—with digital reference command
0.1%—with analog reference command; 10 bits/10 V
Frequency reference resolution Digital: 0.01 Hz; analog: 0.03 Hz (at 60 Hz)
Output frequency resolution 0.01 Hz
Overload capacity 150% of drive rated load for 1 min
Remote frequency reference
sources
0–10 VDC (20k); 4–20 mA (250); ±10 VDC serial (RS-485)
Accel/decel times 0.1 to 6000.0 sec—4 sets; 8 parameters are independently adjustable
Braking torque 150% or more with dynamic braking
DC Link Choke Models 2085 to 2415 and 4045 to 41090 come with a built-in DC link choke.
Internal Braking Transistor Models 2003 to 2115, 4001 to 4060, and 5001 to 5041 come with an internal
braking transistor (B1 and B2 terminals).
Motor overload protection UL recognized electronic thermal overload relay; field-programmable
Overcurrent protection level
(OC1)
200% of drive rated current
Circuit protection Ground fault and blown-fuse protection
Overvoltage protection level 230 VAC class: Stops when DC bus voltage exceeds approx. 410 VDC
460 VAC class: Stops when DC bus voltage exceeds approx. 820 VDC
575 VAC class: Stops when DC bus voltage exceeds approx. 1040 VDC
Undervoltage protection level 230 VAC class: Stops when DC bus voltage falls below approx. 190 VDC
460 VAC class: Stops when DC bus voltage falls below approx. 380 VDC
575 VAC class: Stops when DC bus voltage falls below approx. 475 VDC
* 2kHz carrier frequency
** Maximum rated temperature of 65°C at the drive chassis with factory approved air handling system
