Magnetek Impulse G+ series 4 User Manual

IMPULSE®•G+ & VG+ Series 4 Instruction Manual – February 2017
5-110
Table 5-90: Speed Agree Parameters
Table 5-91: Reference Detection Parameter Settings
Parameter Display Function Range Default
L04-01 Spd Agree Level Sets the detection level for the
desired speed agree 1 and
frequency detection functions. The
detection level is effective during
both FWD and REV operation.
0.0–150.0 Hz 0.0
L04-02 Spd Agree Width Sets the detection width for speed
agree 1 and frequency detection
functions.
0.0–20.0 Hz 2.0
L04-03 Spd Agree Lvl+- Sets the detection level for the
desired speed agree 2 function. The
detection level is effective during
either FWD or REV operation,
depending on the set detection level
(positive value for FWD operation,
negative value for REV operation).
-150.0–150.0 Hz 0.0
L04-04 Spd Agree Wdth+- Sets the detection width for the
speed agree 2 function.
0.0–20.0 Hz 2.0
Parameter Display Function Range Default
L04-05 Ref Loss Sel The drive can detect a loss of an
analog frequency reference from
input A1, A2, or A3. Frequency
reference loss is detected when the
frequency reference drops below
10% of the reference or below 5% of
the maximum output frequency
within 400 ms.
0, 1 0
0Stop Drive stops when the frequency
reference is lost.
1 Run@L4-
06PrevRef
Drive runs at a reduced speed when
the frequency reference is lost.
L04-06 Fref at Floss Sets the percentage of the
frequency reference that the drive
should run with when the frequency
reference is lost.
0.0–100.0% 80
L04-07 Freq Detect Sel Determines when frequency
detection is active using parameters
L04-01 through L04-04.
0, 1 0
0 No Detection @BB No detection during baseblock.
1 Always Detected Detection always enabled.
