IMPULSE®•G+ & VG+ Series 4 Instruction Manual – February 2017
5-134
Table 5-113: Fault History Parameters
U02-15
SFS Output Displays the speed reference for the soft starter at the
previous fault (U02-02).
Hz
U02-16
Motor Iq Current Displays the q-axis current for the motor at the previous fault
(U02-02).
%
U02-17
Motor Id Current Displays the d-axis current for the motor at the previous fault
(U02-02).
%
U02-20
Actual Fin Temp Displays the temperature of the heatsink when the most
recent fault occurred.
°C
U02-27*
Motor Temp (NTC) Displays the temperature of the motor when the most recent
fault occurred.
°C
U02-28*
Fault Axis Display the module where the previous fault occurred at a
decimal number.
--
Parameter Display Function Units
U03-01 Last Fault Displays the first most recent fault. --
U03-02 Fault Message 2 Displays the second most recent fault. --
U03-03 Fault Message 3 Displays the third most recent faults. --
U03-04 Fault Message 4 Displays the fourth most recent fault. --
U03-05 Fault Message 5 Displays the fifth most recent fault. --
U03-06 Fault Message 6 Displays the sixth most recent fault. --
U03-07 Fault Message 7 Displays the seventh most recent fault. --
U03-08 Fault Message 8 Displays the eighth most recent fault. --
U03-09 Fault Message 9 Displays the ninth most recent fault. --
U03-10 Fault Message 10 Displays the tenth most recent fault. --
U03-11 Elapsed Time 1 Elapsed time of the first most recent fault. Hrs
U03-12 Elapsed Time 2 Elapsed time of the second most recent fault. Hrs
U03-13 Elapsed Time 3 Elapsed time of the third most recent fault. Hrs
U03-14 Elapsed Time 4 Elapsed time of the fourth most recent fault. Hrs
U03-15 Elapsed Time 5 Elapsed time of the fifth most recent fault. Hrs
U03-16 Elapsed Time 6 Elapsed time of the sixth most recent fault. Hrs
U03-17 Elapsed Time 7 Elapsed time of the seventh most recent fault. Hrs
U03-18 Elapsed Time 8 Elapsed time of the eighth most recent fault. Hrs
U03-19 Elapsed Time 9 Elapsed time of the ninth most recent fault. Hrs
U03-20 Elapsed Time 10 Elapsed time of the tenth most recent fault. Hrs
U03-21 RUN Cmd Counter Counts FWD or REV run commands Count
U03-22 U3-21 Rollovers Increments when U03-21 passes 9999. U03-21 is set to 0.
Counter cleared by O03-14.
Count
U03-23 OL/LC Count Counts OL1, OL2, LC faults. Counter cleared by O03-14. Count
Parameter Display Function Units
* Available only for 4810 and 41090 models.

Magnetek Impulse G+ series 4 Specifications

General

Output Frequency	0 - 400 Hz
Humidity	5% to 95% non-condensing
Dimensions	Varies by model
Weight	Varies by model
Enclosure	NEMA 1, NEMA 12, NEMA 4
Communication	Profibus
Output Current	Varies by model
Control Method	Closed Loop Vector Control
Display	LCD
Protection Features	Overcurrent, Overvoltage, Undervoltage, Short Circuit
Operating Temperature	-10°C to 50°C
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
