Magnetek Impulse G+ series 4 User Manual

IMPULSE®•G+ & VG+ Series 4 Instruction Manual - February 2017
1-11
Table 1-6: 575 V Class
Model Number 600 V Part Number Maximum Amps of Reactor
5001-G+/VG+S4 REA575-1 2
5003-G+/VG+S4 REA575-2 4
5004-G+/VG+S4 REA575-3 4
5006-G+/VG+S4 REA575-5 8
5009-G+/VG+S4 REA575-10 12
5012-G+/VG+S4 REA575-10 12
5017-G+/VG+S4 REA575-15 18
5022-G+/VG+S4 REA575-20 & 25 25
5027-G+/VG+S4 REA575-30 35
5032-G+/VG+S4 REA575-30 35
5041-G+/VG+S4 REA575-40 45
5052-G+/VG+S4 REA575-50 55
5062-G+/VG+S4 REA575-60 80
5077-G+/VG+S4 REA575-75 80
5099-G+/VG+S4 REA575-100 100
5130-G+/VG+S4 REA575-150 160
5172-G+/VG+S4 REA575-200 200
5200-G+/VG+S4 REA575-200 200
