IMPULSE®•G+ & VG+ Series 4 Instruction Manual – February 2017
A-3
IMPULSE
®
•G+ & VG+ Series 4 Parameter Listing
Parameter Parameter Name Default Range Units Reference
A01-01 Access Level 2 0–2 -- 4-9
A01-02 Control Method 3 0, 2, 3 -- 4-9
A01-03 Motion G+: 1
VG+: 2
0–2, 4 -- 4-10
A01-04 Speed Reference * 0–8 -- 4-10
A01-05 Init Parameters 0 0–8880 -- 4-15
A01-06 Enter Password 1 0 -- -- 4-15
A02-01 to
A02-32
User Parameters -- -- -- 4-16
B01-01 Reference 1 15.00* 0.00–E1-04 Hz 5-3
B01-02 Reference 2 30.00* 0.00–E1-04 Hz 5-3
B01-03 Reference 3 60.00* 0.00–E1-04 Hz 5-3
B01-04 Reference 4 0.00* 0.00–E1-04 Hz 5-3
B01-05 Reference 5 0.00* 0.00–E1-04 Hz 5-3
B01-06 Reference 6 0.00* 0.00–E1-04 Hz 5-3
B01-07 Reference 7 0.00* 0.00–E1-04 Hz 5-3
B01-08 Reference 8 0.00* 0.00–E1-04 Hz 5-3
B01-09 Reference 9 0.00* 0.00–E1-04 Hz 5-3
B01-10 Reference 10 0.00* 0.00–E1-04 Hz 5-3
B01-11 Reference 11 0.00* 0.00–E1-04 Hz 5-3
B01-12 Reference 12 0.00* 0.00–E1-04 Hz 5-3
B01-13 Reference 13 0.00* 0.00–E1-04 Hz 5-3
B01-14 Reference 14 0.00* 0.00–E1-04 Hz 5-3
B01-15 Reference 15 0.00* 0.00–E1-04 Hz 5-3
B01-16 Reference 16 0.00* 0.00–E1-04 Hz 5-3
B01-17 Jog Reference 6.00 0.00–E1-04 Hz 5-3
B01-18 Ref Priority 0* 0–2 -- 5-3
B02-01 Ref Upper Limit 100.0* 0.0–110.0 % 5-5
B02-02 Ref Lower Limit 0.0 0.0–110.0 % 5-5
B02-03 Ref1 Lower Limit 2.0* 0.0–110.0 % 5-5
B02-04 Alt Upper Limit 0.0 0.0–110.0 % 5-5
B03-01 Ref Source 1 1* 0–4 -- 5-6
B03-02 Run Source 1 1* 0–3 -- 5-6
B03-03 Stopping Method G+: 0*
VG+: 6*
0, 1, 4, 6 -- 5-7
B03-04 Change Rotation 0 0, 1 -- 5-9
B03-05 Zero-Speed Oper 0 0–3 -- 5-9
B03-06 Ctnl Input Scans 1 0, 1 -- 5-9
* Initial value set by X-Press Programming (Table 4-6, 4-7, or 4-8 on pages 4-12, 4-13, and 4-14).
** Initial value dependent on drive size, which is determined by O02-04 (kVA Selection).
*** Value is automatically set during auto tuning.
**** 0.0–25.5 seconds is extended to 0.0–6000.0 seconds when B05-16 = 1.
