IMPULSE®•G+ & VG+ Series 4 Instruction Manual - February 2017
2-13
Table 2-3: Enclosure Dimensions - 575 V Drives
Drive Model
Number
(-G+/VG+S4)
Dimensions (in)
Total
Loss
(W)*
Figure W H D W1 W2 H1 H2 H4 D1 t1 t2 d
Wt.
(lbs)
5001
2-5
5.51 10.24 5.79 4.80 -- 9.76 -- 0.06 1.50 0.20 -- M5 7.5 48.7
5003 5.51 10.24 5.79 4.80 -- 9.76 -- 0.06 1.50 0.20 -- M5 7.5 81.9
5004 5.51 10.24 6.46 4.80 -- 9.76 -- 0.06 2.17 0.20 -- M5 8.2 80.0
5006 5.51 10.24 6.46 4.80 -- 9.76 -- 0.06 2.17 0.20 -- M5 8.2 115.1
5009 5.51 10.24 6.57 4.80 -- 9.76 -- 0.06 2.17 0.20 -- M5 9.0 160.3
5012 7.09 11.81 7.36 6.30 -- 11.18 -- 0.06 2.95 0.20 -- M5 13.2 212.2
5017 7.09 11.81 7.36 6.30 -- 11.18 -- 0.06 2.95 0.20 -- M5 13.2 284.8
5022 8.66 13.78 7.76 7.56 -- 13.19 -- 0.06 3.07 0.20 -- M6 19.2 381.1
5027 8.66 13.78 7.76 7.56 -- 13.19 -- 0.06 3.07 0.20 -- M6 19.2 465.1
5032
2-6
10.98 17.72 10.16 8.66 0.31 17.13 0.30 -- 3.94 0.09 0.09 M6 59.5 533.5
5041 10.98 17.72 10.16 8.66 0.31 17.13 0.30 -- 3.94 0.09 0.09 M6 59.5 688.5
5052 12.95 21.65 11.14 10.24 0.31 21.06 0.30 -- 4.33 0.09 0.09 M6 99.2 1606.5
5062 12.95 21.65 11.14 10.24 0.31 21.06 0.30 -- 4.33 0.09 0.09 M6 99.2 1836.5
5077 12.95 21.65 11.14 10.24 0.31 21.06 0.30 -- 4.33 0.09 0.09 M6 99.2 1619.0
5099 17.72 27.76 12.99 12.80 0.39 26.77 0.49 -- 5.12 0.13 0.13 M10 174.2 1750
5130 17.72 27.76 12.99 12.80 0.39 26.77 0.49 -- 5.12 0.13 0.13 M10 174.2 2146
5172 19.69 31.50 13.78 14.57 0.39 30.43 0.51 -- 5.12 0.18 0.18 M12 235.9 2762
5200 19.69 31.50 13.78 14.57 0.39 30.43 0.51 -- 5.12 0.18 0.18 M12 235.9 3422
* Total Loss is specified for continuous operation.
