Valve Guide / Oil Scraper Ring
Inspection / Replace
A5.05. 01.05.01.00
30000
M20
en / 29.05.2000 IB021088 2/2
01
Ĺ
2. Measurement of the valve guide clearance.
2.1 Measure the outside diameter of the valve stem in the zone of the guide bush.
2.2 Measure the inside diameter of the guide bush in traverse direction of the engine.
2.3
Normal clearance (mm) Limit clearance (mm)
Exhaust
Inlet 0.10 - 0.17 0.4
3. Replacement of the valve guide
Note:
If possible replace the valve guide in the workshop of a MaK dealer during the overhaul of
cylinder head. There is a risk that the cylinder cover may be damaged when the old valve
guide is knocked out.
