Cylinder Head
Maintenance / Disassembly
A5.05. 01.06.01.00
M20
en / 11.07.2001 IB001347 1/4
01
Ĺ
See also: 01.02.01.nn, 02.06.01.nn, 06.01.01.nn
Spare parts list: B1.05.01.2.2107
Time requirement: 1 Pers./ 0,50 h
Personnel qualification: skilled engine hand
---------------------------------------------------------------------------------------------------------------------
Operating medium: Heavy fuel and distillate fuel
Tools:
Hydr. equipment set consisting of
High-pressure pump W1 0.9204-D
High-pressure hose (1 m) W2 0.9205-B
High-pressure hose W3 0.9205-C
Hydr. tensioning element W4 0.9213-A
Distributor W5 0.9203-8
Bearing ring W6 0.9203-108
Spacer W7 0.9203-107
Pin W8 0.9203-110
Cylinder head lifting device W9 * 2.9221-A
Turning rod W10 * 2.9100-380
Cylinder liner hold-down W11 * 2.9217-A
* not available as figure
Note:
When lifting the cylinder head or when turning afterwards, the liner is always to be secured
with the hold-down in order to prevent the liner from becoming loose.
Attention:
Do not fall below minimum bending radius r = 120 mm of the high-pressure hoses. Only
use hydraulic oil as an operating material (see Section A4.05.08, “Operating materials”).
Store equipment protected against corrosion.
ĭ Safety note:
No parts of the body should be over the equipment which is under pressure. Secure
engine against unintentional starting.
Sequence of operations:
1. Mount liner holding device (W11) (02.06.01.nn). Turn the piston to firing TDC. Remove
cylinder head cover and pump room lining.
2. Drain cooling water completely into a draining tank (connecting line: distributor line inlet/
outlet open).
Inspection:
Unscrew plug in pressure line behind cooling water pump after return valve.
