Nozzle Sleeve
Maintenance / Disassembly and reassembly
A5.05. 01.06.50.00
15000
M20
en / 05.06.2000 IB021941 2/2
01
Ĺ
2. Mount the nozzle sleeve
2.1 Apply a film of green soft soap to the new black O-ring and insert it in the groove (4). Make
sure the O-ring is not twisted.
2.2 Apply a film of green soft soap to the new green O-ring and insert it in the groove (3). Make
sure the O-ring is not twisted.
Attention:
Do not change the position of the O-rings. Observe the mounting instructions.
2.3 Grease the threads of the nozzle sleeve with high-temperature thread paste.
2.4 Insert the nozzle sleeve and tighten the sleeve with the pin spanner (hand-tight).
2.5 Tighten the nozzle sleeve at a torque of
M =100 Nm.
