Piston
Maintenance / Disassembly
A5.05. 02.06.01.02
M20
en / 28.01.2000 IB004756 3/3
02
Ĺ
Attention:
Make sure that the calibration ring is drawn out smoothly when removing the piston.
If the calibration ring becomes tilted, lower the piston and align the calibration ring.
The connecting rod must not strike the crank pin; if necessary turn the crank pin to
the side.
17. Drop the piston in the appropriate direction.
