Lubricating Oil Duplex Filter
Maintenance / Cleaning
A5.05. 08.04.01.00
M20
en / 03.06.1998 IB001418 4/4
08
Ĺ
2.4.6 Introduce the pistol into the cartridge, pull the trigger and move down to the bottom
of each filter candles.
2.4.7 Remove sticking dirt with a soft brush.
Note:
If possible, clean the filter elements from the ouside with a high-pressure cleaner.
Working pressure of the high-pressure cleaner max. 60 bar. Cleansing agent: Warm water
or water with cleansing liquid.
Attention:
When cleaning with the high-pressure cleaner, be careful not to hold the nozzle too close
to the gauze in order to avoid damage and/or displacement of the gauze wires.
2.4.8 Rinse the filter candles in clean cleansing liquid, blow through with air and allow them to
dry with the opening facing downwards.
2.4.9 Put a strong light behind the gauze and check the cleaning operation. Repeat it if necessary.
2.4.10 Fit the filter candles in reverse order as described under 2.4.3. The O-ring between element
plate and filter candles must be free from cracks and deformation.
3. Check the gasket between element plate and filter housing and renew it if necessary.
4. Fit the element in the filter chamber.
5. Fit the cover (renew the gasket).
6. Fill the filter chamber and vent it (see the plate on the filter cover).
