RPM Switch
Inspection / Adjust
A5.05. 11.05.01.01
7500
M20/M25/M32/M453C/M552C
en / 31.05.2000 IB021724 2/2
11
Ĺ
5.2 PICK UP IMPULSE (dependent upon engine speed up to 1500 Hz at contact b14 and d14).
If nothing could be detected whilst checking points 4 - 6, renew the plug-in card.
Attention:
Carry out the rpm adjustment of the new plug-in card. For this see the "Plant components
file (C), section 5, rpm switch".
