Connection of shipyard-side wiring
102
Read this manual carefully before starting any work!
This is particularly applicable to the chapter “General Safety Instructions”
and the respective safety instructions in the chapters.
10.2.1 Connection of a start and stop apparatus (in case of non classified)
Starting and stopping the engine can also be actuated by:
1. an ignition switch
2. a button (without ignition switch)
In this case the ignition is switched on‐ and off via the impulse. The engine is also started using a
button (engine start button), as well as the engine stop (engine stop button).
A combination of both options is not possible (either 1 or 2). Connection via shipyard plug X4.
Option 1: Ignition lock Option 2: Button
Furthermore, the engine can also be started and stopped via the display when the ignition is switched on.
