Interface CAN-2 touch display
145
Read this manual carefully before starting any work!
This is particularly applicable to the chapter “General Safety Instructions”
and the respective safety instructions in the chapters.
18.2.10 Transmission Fluids
Transmission repetition rate: 1000 ms
Data length: 8 bytes
Identifier: 0x18 FE F8 27
Byte 1: Default Value = 0xFF
Not supported
Byte 2: Transmission Oil Level
0.4 % per bit
0 % offset
Range: 0 % ... 100 %
SAEJ1939-71: SPN 124
only two states supported:
0 % Low level detected
100 % No low level detected
Byte 2: Transmission Filter Differential Pressure
20 mbar per bit
0 mbar offset
Range: 0 ... 5 bar
SAEJ1939-71: SPN 126
Byte 3: Transmission Oil Pressure
160 mbar per bit
0 mbar offset
Range: 0 ... 40 bar
SAEJ1939-71: SPN 127
Byte 4: Transmission Oil Temperature
0.03125 °C per bit
-273 °C offset
Range: -273 °C ... 1735 °C
SAEJ1939-71: SPN 177
Byte 3 - 8: Default Value = 0xFF FF
Not supported
