Engine operation panels
111
Read this manual carefully before starting any work!
This is particularly applicable to the chapter General Safety Instructions and the
respective safety instructions in the chapters.
12.1.3 Installing the Engine Operation Panel EOP
The Engine Operation Panel EOP is integrated in the bridge console. For safe ship operation, the front
buttons must be easily accessible.
For the dimensions of the Engine Operation Panel EOP, see page
Technical data
General data
Dimensions, W x H x D: 70 x 130 x 65 mm
Console section, Bx H: 60 x 113 mm
Weight: approx. 0.5 kg
Environmental data
Operating temperature: -25 °C - +70 °C
Storage temperature: -30 °C - +85 °C
Protection class: IP 67 (front), IP 65 (rear)
Electrical data
Voltage supply: 9 - 32 VDC
Performance/power
consumption:
max. 400 mA
Interfaces, cable end: 2x M12 circular connectors (socket, 8-pin)
Ignition release, cable end:
(IGN-FREE)
1 isolated relay contact, NO, 24 V DC/8A
