Interface CAN-2 touch display
141
Read this manual carefully before starting any work!
This is particularly applicable to the chapter “General Safety Instructions”
and the respective safety instructions in the chapters.
18.2.4 Turbocharger Info 5
Transmission repetition rate: 500 ms
Data length: 8 bytes
Identifier: 0x18 FE 97 27
Byte 1, 2: Exhaust temperature after turbo 1
0.03125 °C per bit
-273 °C offset
Range: -273 °C ... 1735 °C
SAEJ1939-71: SPN 1184
Byte 3, 4: Exhaust temperature after turbo 2
0.03125 °C per bit
-273 °C offset
Range: -273 °C ... 1735 °C
SAEJ1939-71: SPN 1185
Byte 5 - 8: Default Value = 0xFF FF FF FF
Not supported
18.2.5 Engine Temperature
Transmission repetition rate: 1000 ms
Data length: 8 bytes
Identifier: 0x18 FE EE 27
Byte 1: Engine coolant temperature
1 °C per bit
-40 °C offset
Range: -40 °C ... 210 °C
SAEJ1939-71: SPN 110
Byte 2: Fuel temperature
1 °C per bit
-40 °C offset
Range: -40 °C ... 210 °C
SAEJ1939-71: SPN 174
Byte 3, 4: Engine oil temperature
0.03125 °C per bit
-273 °C offset
Range: -273 ... 1735.0 °C
SAEJ1939-71: SPN 175
Byte 5 - 8: Default Value = 0xFF FF FF FF
Not supported
