6.2.4 Connector board
Installation location:
The connector board is attached at the front in the terminal box
(1) Connector board
Function
The connector board establishes signal connections between the external connections for the cable
harness and between the above-mentioned components.
It is the central connection of connecting cables and engine cable harnesses.
