Interface CAN-2 touch display
139
Read this manual carefully before starting any work!
This is particularly applicable to the chapter “General Safety Instructions”
and the respective safety instructions in the chapters.
Byte 4, 5: Actual engine speed
0.125 rpm per bit
0 rpm offset
Range: 0 rpm ... 8031.875 rpm
SAEJ1939-71: SPN 190
Byte 6: Source address of controlling device for Engine Control
0x00: EDC17 (drive leverage to EDC17 for classes-engines)
0x27 MCS (idle or drive leverage)
0xD0 Driving from Emergency stand 1
0xD1 Driving from Emergency stand 2
0xD2 Driving from Emergency stand 3
0xD3 Driving from Emergency stand 4
0xD4 Driving from Emergency stand 5
0xD5 Driving from Emergency stand 6
0xF2 Local drive from Engine Display
SAEJ1939-71: SPN 1483
Byte 7: (Control Bits)
Bit 1-4: Engine Starter Mode
000bin Start not requested
001bin Before Start
010bin Start
100bin After Start
SAEJ1939-71: SPN 1675
Bit 5-8: Default Value = 0xF
Not supported
Byte 8: Engine Demand, percent torque
0x FF
Not supported
