Control and operation
95
Read this manual carefully before starting any work!
This is particularly applicable to the chapter “General Safety Instructions”
and the respective safety instructions in the chapters.
Error print process (emissions history)
Emissions-related “alarms”:
The operator is offered the following access and printing options for reading out the emissions history
memory:
access to the emissions history memory:
The read-out can be effected via a standard laptop with a specific URL: “https://XXXXXXX.nme.man”.
This URL only functions with a 7-digit resource number of the 14-digit engine serial number that is marked
on the model label of the engine or on the E-box.
Connection to the laptop is effected via X28 plug on the E-box. Here, any standard browser such as Mozilla
Firefox or Microsoft Internet Explorer can be used to create a print-out.
In each case, the emissions history memory is only shown for one engine.
The print-out contains the following information:
S Date of printing including the operating hours of
the engine at the time of print-out
S Engine type and serial number
S Actual engine operating hours and date when
- the system activated an emissions-related
alarm
- the operator confirmed the emissions-related
alarm
- the system detected regeneration of the
emissions-related alarm
S Error code and text message
Procedure:
1. Read off 7-digit resource number (1) of the
14-digit engine serial number on model label or
E-box (see example image)
2. Establish local connection between notebook
and E-box via X28 plug
3. Open Web browser Mozilla Firefox
(recommended) (alternatively, Google
Chrome/Microsoft Internet Explorer)
4. Enter the read-off 7-digit (XXXXXXX) resource
number with following address into the URL
search bar: “XXXXXXX.nme.man”
5. Confirm URL page (not secure) until the
homepage “Marine Web Interface” opens
6. Home/information/emissions memory and
further information can now be retrieved via
the menu on the homepage.
