Grove Published 01-29-2015, Control # 512-01 3-5
TMS700E SERVICE MANUAL ELECTRIC SYSTEM
3
F14 10
Crane Function SOLS, Hyd Boost
SOL
F15 5 Main, Aux Hoist Rotation Indicators
F16 25
Heater, A/C Evap Fans, A/C Clutch
Solenoid
F17 30 A/C Condenser Fan Motor
F18 10
Beacon LT, Wiper, Washer, Switch
LEDS
F19 5 Buzzer, DEF Level Gauge
F20 20
Outriggers, Counterweight
Solenoids
Fuse Amp Fuse Assignment
FIGURE 3-2
Reference Only
