ELECTRIC SYSTEM TMS700E SERVICE MANUAL
3-6 Published 01-29-2015, Control # 512-01
FIGURE 3-3
Partial Rear View Of Cab
Item Description
1 Fuse Installation
2 Fuse and Relay Panel
3 Harness Connector
4 Harness Connector
5 RCL Cable
1
2
3
4
5
6871-1
NOTE: Refer to (Figure 3-2, 3-3, and 3-4), and Table 3-
3 and 3-4 for fuse and relay identification.
6871-2
Reference Only
