Manitowoc Grove TMS700E

POWER TRAIN TMS700E SERVICE MANUAL
7-26 Published 01-29-2015, Control # 512-01
Item Description
1 Radiator/Charge Air Cooler
2 Recovery Tank
3Drain Cock
4 Left Hand Baffle
5 Right Hand Baffle
6 Top Radiator Tube (QSM)
7 Bottom Radiator Tube (QSM)
8 Cold CAC Tube (QSM)
9 Hot CAC Tube (QSM)
10 Radiator Mount
11 Fan Guards
12 Coolant Recovery Hose
13 Vent Hoses
FIGURE 7-9
1
4
6
2
7
8
10
7
5
3
9
11
10
13
QSM Engine Radiator/Charge Air Cooler Assembly
12
Reference Only
