HYDRAULIC SYSTEM TMS700E SERVICE MANUAL
2-36 Published 01-29-2015, Control # 512-01
Item Description
1 A Port - Swing Right
2 B Port - Swing Left
3 T Port - Tank Port
4 P Port - Pressure Port
5 A Port - Telescope Out or Auxiliary Hoist Down
Item Description
6 Telescope In or Auxiliary Hoist Up
7 A Port - Lift Down
8 B Port - Lift Up
9 A Port - Main Hoist Down
10 B Port - Main Hoist Up
FIGURE 2-23 continued
4
2
1
3
1
3
2
5
4
TELESCOPE FOOT
CONTROLLER
Item Description
1 Port P - Pressure
2 Port 1 - Telescope Out
3 Port 2 - Telescope In
Item Description
4 Port T - Tank
5 Case Drain - Manifold
Reference Only
