ENGLISH
OPERATOR'S MANUAL
52
Cod. EKE0002OM
Harrow height of 50mm from the ground is suitable for most field conditions. If you
perform collection too low, it may collect dust and rocks along with the crop. This may
damage or wear collecting components. (Figure 2)
Figure 2
Collection unit floating spring bears majority of collection group during bale machine
operation. Install floating spring (1) and threaded adjustment rod (2) as illustrated in Figure 3,
and lock with double nuts. Adjust threaded rod end (3) nut distance as 30-20mm.
Figure 3
