7. DIAGNOSTIC AND TROUBLESHOOTING
Some of the possible problems that may occur on PITAGORA INLINE Baler and their
solutions are given in the following table.
7.1. PTO Shaft Area
PTO shaft area problems and solutions are given in Table 7.1.1.
Table 7.1.1 PTO shaft area problems and solutions
PROBLEM CAUSES SOLUTION
1 ) Universal Joint Failure
1.1 ) Overload.
1.2)
Tractor PTO shaft
revolution is too high when
activating PTO clutch,
resulting in shock load.
1.3)
Short turn are
causing joints to “drop
down”
1.4)
PTO shaft is hitting
against transmission shaft
when tractor wheels are
turning.
1.5)
Wrong drawbar
length, height or alignment.
1.6)
Power transmission
joint or bearing position is
wrong.
1.7 ) Insufficient lubrication.
1.1)
Check PTO shaft
safety clutch. Adjust
according to specifications
in this operating and
maintenance manual.
1.2) Activate w
hen
tractor PTO shaft is in idle.
1.3)
Deactivate PTO
shaft during short turns.
1.4) Increase turning span.
1.5)
Adjust drawbar and
PTO shaft positions.
1.6)
Adjust according to
specifications in this
operating and
maintenance manual.
1.7) Lubricate after ever
y 50
hours.
2 ) Twisted Shaft
2.1)
Tractor PTO shaft is activated
when engine revolution was higher
than idle.
2.2)
PTO shaft clutch is too tight
or stuck.
2.1)
Activate tractor PTO shaft in
idle.
2.2) Check the clutch.
3 ) Vibrations Particularly
During Turns.
3.1) Universal
joints are not
adjusted.
3.2)
Power joint or pillow block
bearing is not adjusted properly.
3.3)
Tractor drawbar length, height
or alignment.
Worn out components.
3.1) Replace the necessary parts.
3.2)
Adjust drawbar according
to correct specifications.
3.3) Replace as necessary.
