Maschio PITAGORA INLINE - Page 72

ENGLISH
OPERATOR'S MANUAL
72
Cod. EKE0002OM
Figure 2
Compression springs (4) inserting into M6X70 adjustment bolts (3) on knotter set lining
must be tightened between 40-43 mm measured from the washer. (Figure 3)
Note: Knotter set linings should be re-adjusted after 10.000 bales depending on
the lining bolt wear amount.
