For Flywheel;
Considering operation time of drawbar, lubricate every 10 hours on daily basis using
grease. (Figure 5.)
Figure 5
For Knotter Set;
Components on the Knotter Set unit are in continuous motion. Therefore, considering
continuous operation time, needle saddle drive rod, eccentric shaft bearings, needle saddle
bearing and bale size adjustment piece should be lubricated on daily basis before starting the
shift. (Figure 6.)
Figure 6
