Masibus Automation VMS4SE User Manual

User Manual 101
VMS4SE(Vibration Monitor)
REF NO: mVMA/om/101
Issue No: 01
272
CSP Status for Ch-8
114. BIT 7
228. BIT 7
0 – 1
273
CSP Status for Ch-9
114. BIT 8
227. BIT 0
Read only
byte
0 – 1
274
CSP Status for Ch-10
114. BIT 9
227. BIT 1
0 – 1
275
CSP Status for Ch-11
114. BIT 10
227. BIT 2
0 – 1
276
CSP Status for Ch-12
114. BIT 11
227. BIT 3
0 – 1
277
CSP Status for Ch-13
114. BIT 12
227. BIT 4
0 – 1
278
CSP Status for Ch-14
114. BIT 13
227. BIT 5
0 – 1
279
CSP Status for Ch-15
114. BIT 14
227. BIT 6
0 – 1
280
CSP Status for Ch-16
114. BIT 15
227. BIT 7
0 – 1
281
CSP Status for Ch-17
113. BIT 0
226. BIT 0
Read only
byte
0 – 1
282
CSP Status for Ch-18
113. BIT 1
226. BIT 1
0 – 1
283
CSP Status for Ch-19
113. BIT 2
226. BIT 2
0 – 1
284
CSP Status for Ch-20
113. BIT 3
226. BIT 3
0 – 1
285
CSP Status for Ch-21
113. BIT 4
226. BIT 4
0 – 1
286
CSP Status for Ch-22
113. BIT 5
226. BIT 5
0 – 1
287
CSP Status for Ch-23
113. BIT 6
226. BIT 6
0 – 1
288
CSP Status for Ch-24
113. BIT 7
226. BIT 7
0 – 1
Relay Status (0 = OFF, 1 = ON)
Sr. No.
Digital Parameters
Absolute
Address
(word)
Absolute
Address
Type of
Access
Parameter
Type
Values
Applicable
(byte)
289
Relay Status for Relay - 1
116. BIT 0
232. BIT 0
Read
only
byte
0 - 1
290
Relay Status for Relay - 2
116. BIT 1
232. BIT 1
0 – 1
291
Relay Status for Relay - 3
116. BIT 2
232. BIT 2
0 – 1
292
Relay Status for Relay - 4
116. BIT 3
232. BIT 3
0 – 1
293
Relay Status for Relay - 5
116. BIT 4
232. BIT 4
0 – 1
294
Relay Status for Relay - 6
116. BIT 5
232. BIT 5
0 – 1
295
Relay Status for Relay - 7
116. BIT 6
232. BIT 6
0 – 1
296
Relay Status for Relay - 8
116. BIT 7
232. BIT 7
0 – 1
Open Collector Status (0 = OFF, 1 = ON)
Sr. No.
Digital Parameters
Absolute
Address
(word)
Absolute
Address
Type of
Access
Parameter
Type
Values
Applicable
(byte)
297
Open Collector Status for
Open Collector - 1
116. BIT 8
231. BIT 0
Read
only
byte
0 - 1
298
Open Collector Status for
Open Collector - 2
116. BIT 9
231. BIT 1
0 – 1
299
Open Collector Status for
Open Collector - 3
116. BIT 10
231. BIT 2
0 – 1
300
Open Collector Status for
Open Collector - 4
116. BIT 11
231. BIT 3
0 – 1
