Masibus Automation VMS4SE User Manual

User Manual 100
VMS4SE(Vibration Monitor)
REF NO: mVMA/om/101
Issue No: 01
Alarm Set Point 2 (ASP2) Status of individual channel (0 = LED OFF, 1 = LED ON)
Sr. No.
Digital Parameters
Absolute
Address
(word)
Absolute
Address
Type of
Access
Parameter
Type
Values
Applicable
(byte)
241
ASP2 Status for Ch-1
112. BIT 0
224. BIT 0
Read only
byte
0 - 1
242
ASP2 Status for Ch-2
112. BIT 1
224. BIT 1
0 – 1
243
ASP2 Status for Ch-3
112. BIT 2
224. BIT 2
0 – 1
244
ASP2 Status for Ch-4
112. BIT 3
224. BIT 3
0 – 1
245
ASP2 Status for Ch-5
112. BIT 4
224. BIT 4
0 – 1
246
ASP2 Status for Ch-6
112. BIT 5
224. BIT 5
0 – 1
247
ASP2 Status for Ch-7
112. BIT 6
224. BIT 6
0 – 1
248
ASP2 Status for Ch-8
112. BIT 7
224. BIT 7
0 – 1
249
ASP2 Status for Ch-9
112. BIT 8
223. BIT 0
Read only
byte
0 – 1
250
ASP2 Status for Ch-10
112. BIT 9
223. BIT 1
0 – 1
251
ASP2 Status for Ch-11
112. BIT 10
223. BIT 2
0 – 1
252
ASP2 Status for Ch-12
112. BIT 11
223. BIT 3
0 – 1
253
ASP2 Status for Ch-13
112. BIT 12
223. BIT 4
0 – 1
254
ASP2 Status for Ch-14
112. BIT 13
223. BIT 5
0 – 1
255
ASP2 Status for Ch-15
112. BIT 14
223. BIT 6
0 – 1
256
ASP2 Status for Ch-16
112. BIT 15
223. BIT 7
0 – 1
257
ASP2 Status for Ch-17
111. BIT 0
222. BIT 0
Read only
byte
0 – 1
258
ASP2 Status for Ch-18
111. BIT 1
222. BIT 1
0 – 1
259
ASP2 Status for Ch-19
111. BIT 2
222. BIT 2
0 – 1
260
ASP2 Status for Ch-20
111. BIT 3
222. BIT 3
0 – 1
261
ASP2 Status for Ch-21
111. BIT 4
222. BIT 4
0 – 1
262
ASP2 Status for Ch-22
111. BIT 5
222. BIT 5
0 – 1
263
ASP2 Status for Ch-23
111. BIT 6
222. BIT 6
0 – 1
264
ASP2 Status for Ch-24
111. BIT 7
222. BIT 7
0 – 1
Control Set Point (CSP) Status of individual channel (0 = LED OFF, 1 = LED ON)
Sr. No.
Digital Parameters
Absolute
Address
(word)
Absolute
Address
Type of
Access
Parameter
Type
Values
Applicable
(byte)
265
CSP Status for Ch-1
114. BIT 0
228. BIT 0
Read only
byte
0 - 1
266
CSP Status for Ch-2
114. BIT 1
228. BIT 1
0 – 1
267
CSP Status for Ch-3
114. BIT 2
228. BIT 2
0 – 1
268
CSP Status for Ch-4
114. BIT 3
228. BIT 3
0 – 1
269
CSP Status for Ch-5
114. BIT 4
228. BIT 4
0 – 1
270
CSP Status for Ch-6
114. BIT 5
228. BIT 5
0 – 1
271
CSP Status for Ch-7
114. BIT 6
228. BIT 6
0 – 1
