Masibus Automation VMS4SE User Manual

User Manual 99
VMS4SE(Vibration Monitor)
REF NO: mVMA/om/101
Issue No: 01
207
Input Type for Ch-15
80
159 (Higher Byte)
write only
byte
0 - 18
208
Input Type for Ch-16
80
160 (Lower Byte)
write only
byte
0 - 18
209
Input Type for Ch-17
81
161 (Higher Byte)
write only
byte
0 - 18
210
Input Type for Ch-18
81
162 (Lower Byte)
write only
byte
0 - 18
211
Input Type for Ch-19
82
163 (Higher Byte)
write only
byte
0 - 18
212
Input Type for Ch-20
82
164 (Lower Byte)
write only
byte
0 - 18
213
Input Type for Ch-21
83
165 (Higher Byte)
write only
byte
0 - 18
214
Input Type for Ch-22
83
166 (Lower Byte)
write only
byte
0 - 18
215
Input Type for Ch-23
84
167 (Higher Byte)
write only
byte
0 - 18
216
Input Type for Ch-24
84
168 (Lower Byte)
write only
byte
0 - 18
Alarm Set Point 1 (ASP1) Status of individual channel (0 = LED OFF, 1 = LED ON)
Sr. No.
Digital Parameters
Absolute
Address
(word)
Absolute
Address
Type of
Access
Parameter
Type
Values
Applicable
(byte)
217
ASP1 Status for Ch-1
110. BIT 0
220. BIT 0
Read only
byte
0 - 1
218
ASP1 Status for Ch-2
110. BIT 1
220. BIT 1
0 – 1
219
ASP1 Status for Ch-3
110. BIT 2
220. BIT 2
0 – 1
220
ASP1 Status for Ch-4
110. BIT 3
220. BIT 3
0 – 1
221
ASP1 Status for Ch-5
110. BIT 4
220. BIT 4
0 – 1
222
ASP1 Status for Ch-6
110. BIT 5
220. BIT 5
0 – 1
223
ASP1 Status for Ch-7
110. BIT 6
220. BIT 6
0 – 1
224
ASP1 Status for Ch-8
110. BIT 7
220. BIT 7
0 – 1
225
ASP1 Status for Ch-9
110. BIT 8
219. BIT 0
Read only
byte
0 – 1
226
ASP1 Status for Ch-10
110. BIT 9
219. BIT 1
0 – 1
227
ASP1 Status for Ch-11
110. BIT 10
219. BIT 2
0 – 1
228
ASP1 Status for Ch-12
110. BIT 11
219. BIT 3
0 – 1
229
ASP1 Status for Ch-13
110. BIT 12
219. BIT 4
0 – 1
230
ASP1 Status for Ch-14
110. BIT 13
219. BIT 5
0 – 1
231
ASP1 Status for Ch-15
110. BIT 14
219. BIT 6
0 – 1
232
ASP1 Status for Ch-16
110. BIT 15
219. BIT 7
0 – 1
233
ASP1 Status for Ch-17
109. BIT 0
218. BIT 0
Read only
byte
0 – 1
234
ASP1 Status for Ch-18
109. BIT 1
218. BIT 1
0 – 1
235
ASP1 Status for Ch-19
109. BIT 2
218. BIT 2
0 – 1
236
ASP1 Status for Ch-20
109. BIT 3
218. BIT 3
0 – 1
237
ASP1 Status for Ch-21
109. BIT 4
218. BIT 4
0 – 1
238
ASP1 Status for Ch-22
109. BIT 5
218. BIT 5
0 – 1
239
ASP1 Status for Ch-23
109. BIT 6
218. BIT 6
0 – 1
240
ASP1 Status for Ch-24
109. BIT 7
218. BIT 7
0 – 1
