Masimo Rad-97 Operator's Manual

Rad-97 Chapter 4: Operation
www.masimo.com 50 Masimo
Ref. Feature Description
8
Rad-97 Battery
Charge/AC Power
Indicator
Displays charging status. Provides access to the Battery screen.
The example shows that AC power is connected and the battery
is currently charging.
See AC Power Indicator on page 50and Battery Charge Status
Indicator on page 51.
9 Sounds
Provides access to the Sounds screen to adjust alarm and pulse
tone volume. This icon does not indicate the actual volume level
of the alarm and pulse tone.
See Sounds on page 85.
10 Current Time
Displays the current time and provides access to the
Localization screen, which contains settings related to local
time, language, and geography.
See Localization on page 87.
AC Power Indicator
Whenever Rad-97 is connected to an AC power source and ON, the AC Power Indicator icon
will appear on the display as follows:
Icon Status
Battery is currently charging
Battery is fully charged
Touch the AC Power Indicator icon to view battery charge details. See Rad-97 Battery on page
93.

Masimo Rad-97 Specifications

General

Display Size	7 inches
SpO2 Accuracy	±2% (70-100%)
Pulse Rate Accuracy	±3 bpm
Perfusion Index Range	0.02% to 20%
Pleth Variability Index Range	0% to 100%
SpO2 Range	0% to 100%
SpHb Range	0 to 25 g/dL
SpCO Range	0% to 40%
Battery Type	Rechargeable lithium-ion
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity Range	10% to 95% non-condensing
Display	Color touchscreen
Connectivity	Wi-Fi, Ethernet, Bluetooth
Power Supply	100–240 VAC, 50–60 Hz
Battery Life	Approximately 4 hours
Measurements	SpO2, Pulse Rate, Perfusion Index, Pleth Variability Index, SpHb, SpOC, SpMet, SpCO
Pulse Rate Range	25 to 240 bpm
HbCO Range	0-99%
MetHb Range	0-99%
SpMet Range	0-99%
Data Storage	Internal memory
Alarms	Audible and visual alarms for all parameters
