18 Chapter 1: Before you begin
Matrox Iris GTR safety warnings and key to
symbols
Before connecting to and using your Matrox Iris GTR, you should be aware of
the meaning of the symbols on the smart camera and the important safety
precautions. The following is a list of precautionary symbols on Matrox Iris GTR
and their meaning.
Symbol
a
Description
The case of your Matrox Iris GTR can become quite hot and should not be touched while operating.
Always allow hot surfaces to cool down before touching your Matrox Iris GTR.
o
• Caution: Consult this manual
b
before connecting to and using Matrox Iris GTR. For hardware connection
instructions, refer to Chapter 2: Powering and connecting to your Matrox Iris GTR; for environmental and
electrical specifications and connector pinout descriptions, refer to Appendix B: Technical reference.
This product must be used as specified; otherwise, the protection provided by its components might be
compromised.
• Refer to the Electrical specifications section, in Appendix B: Technical reference of this manual, for voltages
and current ratings.
• There are no serviceable parts inside this product. In case of defect, contact your Matrox representative.
• To maintain IP67 conformity, all unused connectors on your Matrox Iris GTR must be capped and the IP case
must be screwed firmly into place.
• This product meets the requirements of a Category 1 installation as per industry standards
c
.
• This product is designed for use in a pollution degree 2 environment as per industry standards
c
.
• This product is designed for indoor use only.
• This product is designed to operate at temperatures ranging from 0°C to 50°C.
• This product is not intended for use at altitudes exceeding 2000 m.
DC current only.
Your Matrox Iris GTR can only be powered using a 24 V DC power source.
a. Note that these symbols might not necessarily be the same color as depicted.
b. Manual available on the Matrox Imaging website at http://www.matrox.com/imaging
c. As per CAN/CSA-C22.2 No 61010-1-12, UL std. No 61010-1 (3rd edition), and EN Std. No. 61010-1 (3rd Edition)
