66 Appendix B: Technical reference
Environmental specifications
• For indoor use only.
• Maximum altitude: 2000 meters.
• Operating temperature: 0 to 50 C (32 °F to 122 °F)
1
.
• Ventilation requirements: Natural convection.
• Pollution degree: 2 environment.
• Over-voltage category: I
• Ingress protection rating: IP67.
Mechanical specifications
Dimensions
1. Under current testing conditions.
GTR300, GTR300C, GTR1300, GTR1300C, GTR2000, GTR2000C, GTR5000, GTR5000C
Connectors M12 8-pin (female) X-coded connector for 100/1000 BaseT Ethernet.
M12 12-pin (male) connector for VGA/USB.
M12 12-pin (female) connector for digital I/O and power.
Certification IP67
Dimensions GTR300, GTR300C, GTR1300, GTR1300C,
GTR2000, GTR2000C, GTR5000, GTR500C
Weight 460.39 g (16.24 oz)
Smart camera length (without the connectors) 75 mm (2.95") ± 2 mm (0.079")
Smart camera height (without the lens) 54 mm (2.13") ± 2 mm (0.079")
Smart camera width 75 mm (2.95") ± 2 mm (0.079")
IP cap length
(interior from the mounting flange to inside the clear top)
59.5 mm (2.34") ± 2 mm (0.079")
IP cap max lens internal clearance
Length 59 mm (2.32") ± 2 mm (0.079")
Diameter 18 mm (0.71") ± 2 mm (0.079")
