Matrox Iris GTR specifications 65
GTR300, GTR300C, GTR1300, GTR1300C, GTR2000, GTR2000C, GTR5000, GTR5000C
I/O specifications
Opto-isolated output signals Operating voltage 24 V (26 V abs. max)
Sink current 50 mA max
Maximum leakage current 1 μΑ@ 24 V
1 mΑ@ 26 V
ON voltage 0.4 V @ 2 mA
1.1 V @ 25 mA
1.5V @ 50 mA
PTC
a
fuse max. time-to-trip
1 sec @ 0.5 A
OFF to ON response
2 μsec to reach 4 V
b
ON to OFF response
50 μsec to reach 11 V
b
Opto-isolated input signals Operating voltage 24 V (26 V abs. max)
Input current (sink or source)
c
3.5 mA max
d
, 1 mA min
e
ON voltage level
> 11 V
f
OFF voltage level < 4 V
OFF to ON response 6 μsec
ON to OFF response 80 μsec
0-10 V analog control output signal Non-isolated. Supports lighting devices (such as, an Advanced Illumination inline control
system (ICS3), a Smart Vision Lights Brick light, or a similar device).
Note that the 0-10 V is intended for reference voltage only (that is < 1 mA).
a. The PTC is an automatically resetting fuse.
b. This occurred under the following condition: output pulled to 24 V using 1 k
Ω.
c. Regardless whether the signal is sinking or sourcing, this measurement is the same.
d. Maximum input current at maximum ON voltage. Note that the connected device must not limit the current to a value lower than this.
e. Minimum input current at minimum ON voltage. This can be used to calculate bleeding resistor needed for 2-wire proximity sensor.
f. Recommended > 12 V when using Matrox Iris GTR breakout board.
GTR300, GTR300C, GTR1300, GTR1300C, GTR2000, GTR2000C, GTR5000, GTR5000C
Varioptic Caspian C-39N0-160-I2C or C-39N0-250-I2C lens (liquid lens)
Typical Supplied voltage 5 V
Rated current 50 mA
