64 Appendix B: Technical reference
The Matrox Iris GTR works with the Varioptic Caspian C-39N0-160-I2C or
C-39N0-250-I2C lens (liquid lens). This electronically focus-controllable
C-mount lens, fits within the IP lens case, provided with your Matrox Iris GTR.
The Varioptic lens connects to the liquid lens connector inside the lens case
housing of your Matrox Iris GTR.
General care and cleaning
To clean the unit housing, use a small amount of mild detergent cleaner on a
cleaning cloth. Do not pour the cleaner directly onto the unit housing.
To remove dust from the lens cap, use either a can of compressed air or a lens
cloth. The air must be free of oil, moisture, and other contaminants that could
remain on the lens cap.
To clean the glass window of the lens cap, use a small amount of isopropyl alcohol
on a cleaning cloth. Do not pour the alcohol directly on the glass window.
Matrox Iris GTR specifications
The following specifications detail your Matrox Iris GTR.
Electrical specifications
GTR300, GTR300C, GTR1300, GTR1300C, GTR2000, GTR2000C, GTR5000, GTR5000C
Operating voltage for the Matrox Iris GTR under testing conditions 24 V.
Rated current 600 mA
Operating voltage tolerance ± 10%
