60 Appendix B: Technical reference
Matrox Iris GTR smart camera summary
Sensor board
Specifications GTR300 GTR300C GTR1300 GTR1300C
CMOS sensor Geometry 1/4”-type 1/2”-type
Format Monochrome Color Monochrome Color
Make and model ON Semiconductor - Python family (NOIP1SN or NOIP1SE)
Effective resolution (H x V) 640 x 480 1280 x 1024
Frame rate
a
Up to 293 fps Up to 147 fps Up to 85 fps
Up to 35 fps
b
Pixel size (H x V)
4.8
μ m x 4.8 μ m
Gain range 0 to 19.4dB
Exposure speeds
50
μ sec to 4 sec.
External trigger latency
(Typical value measured from OFF to ON)
7.1
μ sec 7.2 μ sec
External trigger to output strobe delay
(Typical value measured from OFF to ON)
9.1
μ sec 9.2 μ sec
a. Frame rate is established solely upon rates of acquisition. Your results will differ when including processing time.
b. Note that these numbers come from tests that store the grabbed images in BGR packed format. When using YUV, planar, or Mono10 packed formats, the frame rate
can be significantly different.
Specifications GTR2000 GTR2000C GTR5000 GTR5000C
CMOS sensor Geometry 2/3”-type 1”-type
Format Monochrome Color Monochrome Color
Make and model ON Semiconductor - Python family (NOIP1SN or NOIP1SE)
Effective resolution (H x V) 1920 x 1200 2592 x 2048
Frame rate
a
Up to 45 fps
Up to 20 fps
b
Up to 21 fps
Up to 8.5 fps
b
Pixel size (H x V)
4.8
μ m x 4.8 μ m
Gain range 0 to 19.4dB
Exposure speeds
50
μ sec to 4 sec.
External trigger latency
(Typical value measured from OFF to ON)
8.0
μ sec 8.0 μ sec
External trigger to output strobe delay
(Typical value measured from OFF to ON)
10
μ sec 10 μ sec
a. Frame rate is established solely upon rates of acquisition. Your results will differ when including processing time.
b. Note that these numbers come from tests that store the grabbed images in BGR packed format. When using YUV, planar, or Mono10 packed formats, the frame rate
can be significantly different.
