Appendix C, Matrox MXO2 Supported Input and Capture Formats
Supported input formats
The following table shows the video input formats that are supported on the
MXO2 video inputs for capturing or recording video. For descriptions of the
MXO2 inputs, see “Inputs” on page 290.
Matrox MXO2 input
Video input
format
HDMI SDI
1
Component S-Video Composite
NTSC — ZZZZ
PAL — ZZZZ
720p @ 50 fps ZZZ——
720p @ 59.94 fps ZZZ——
1080i @ 25 fps ZZZ——
1080i @ 29.97 fps ZZZ——
1080PsF @ 23.98 fps — ZZ——
1080PsF @ 24 fps — Z ———
1080PsF @ 25 fps ZZZ——
1080PsF @ 29.97 fps ZZZ——
1080p @ 23.98 fps ZZ———
1080p @ 24 fps ZZ———
1080p @ 25 fps ZZ———
1080p @ 29.97 fps ZZ———
1080p @ 30 fps ZZ———
1
SDI is not supported on Matrox MXO2 Mini.
