Supported video output formats for monitoring
Matrox MAX H.264 Capture and Telestream
Wirecast
The following table shows the formats that are supported on the MXO2 video
outputs for monitoring the source material that you’re capturing using the Matrox
MAX H.264 Capture application, or streaming/recording using Telestream
Wirecast, based on your selected video input format. For a list of the video input
formats supported on the various MXO2 inputs, see “Supported input formats”
on page 306.
Matrox MXO2 output
Video input format HDMI SDI
1
Component S-Video Composite
NTSC NTSC
PAL PAL
720p @ 50 fps 720p @ 50 fps — —
720p @ 59.94 fps 720p @ 59.94 fps — —
1080i @ 25 fps 1080i @ 25 fps — —
1080i @ 29.97 fps 1080i @ 29.97 fps — —
1080PsF @ 23.98 fps 1080PsF @ 23.98 fps — —
1080PsF @ 24 fps — 1080PsF @ 24 fps — — —
1080PsF @ 25 fps 1080PsF @ 25 fps — —
1080PsF @ 29.97 fps 1080PsF @ 29.97 fps — —
1080p @ 23.98 fps 1080p @ 23.98 fps
—
——
1080p @ 24 fps 1080p @ 24 fps — — —
1080p @ 25 fps 1080p @ 25 fps — — —
1080p @ 29.97 fps 1080p @ 29.97 fps
—
——
1080p @ 30 fps 1080p @ 30 fps
—
——
1
SDI is not supported on Matrox MXO2 Mini.
