Appendix D, Matrox MXO2 Supported Output Formats
Matrox A/V Tools
The following table shows the formats that are supported on the MXO2 video
outputs for monitoring your captured video, based on your editing video format
in Matrox A/V Tools.
Matrox MXO2 output
Editing video format
(capture format)
1
HDMI SDI
2
Component S-Video Composite
NTSC NTSC
PAL PAL
486p @ 23.98 fps 480p @ 59.94 fps NTSC
720p @ 50 fps 720p @ 50 fps — —
720p @ 59.94 fps 720p @ 59.94 fps — —
1080i @ 25 fps 1080i @ 25 fps — —
1080i @ 29.97 fps 1080i @ 29.97 fps — —
1080p @ 23.98 fps 1080p/PsF @ 23.98 fps 1080PsF @ 23.98 fps — —
1080p @ 24 fps 1080p/PsF @ 24 fps
3
———
1080p @ 25 fps 1080p/PsF @ 25 fps 1080PsF @ 25 fps — —
1080p @ 29.97 fps 1080p/PsF @ 29.97 fps 1080PsF @ 29.97 fps
1080p @ 30 fps 1080p @ 30 fps
—
——
1
Video is always captured to the editing video format.
2
SDI is not supported on Matrox MXO2 Mini.
3
1080PsF @ 24 fps is supported on the SDI output only.
